Orbea

LAUFEY H10 2026

LAUFEY H10 2026

283.566 kr
319.900 kr 283.566 kr
Tilboð Uppselt

Litur
Stærð
Skemmtilegt hardtail Trail fjallahjól sem kemur með 140 mm fjöðrun að framan, dropper sætispípu, geymsluhólfi og tekur allt að 2.6" breið dekk. Fullkomið hjól fyrir þau sem eru að byrja og vilja fókusera á að hafa gaman við að hjóla skemmtilega slóða

Til að sjá nánari upplýsingar um hjólið Skoða nánar
Skoða nánar

Íhlutir

Frameset

Frame

Orbea Laufey Hydro Triple Butted 29" Boost 12x148 ISCG 05

Fork

Fox 34 Float AWL Sport 140 Rail QR15x110

Steerer tube

Acros Alloy 1-1/8 - 1-1/2" Integrated

Drivetrain

Crankset

Shimano MT512 32t

Shifters

Shimano Deore M6100 I-Spec EV

Cassette

Shimano CS-M6100 10-51t 12-Speed

Rear derailleur

Shimano SLX M7100 SGS Shadow Plus

Chain

Shimano M6100

Cockpit

Handlebar

OC Mountain Control MC30, Rise20, Width 800

Stem

Alloy 3D forged, 35mm interface, -7º

Brakes

Brakes

Shimano M6100 Hydraulic Disc

Wheels

Wheels

Alloy, Tubeless, 29", 29c, 32H

Tyres

Maxxis Dissector 2.60" 60 TPI Exo TLR

Components

Seatpost

OC Mountain Control MC22, 31.6mm, Dropper

Seatpost Lever

Shimano SL-MT500 I-Spec EV

Saddle

Selle Royal 2058 DRN

Grips

OC Lock On

Accessories

Storage

Accesories Containers

We reserve the right to make changes to the product and component information appearing on this site at any time without notice, including with respect to equipment, specifications, models, colors, and materials.

LAUFEY H10
S
M
L
XL
1Seat Tube (C-T)
380
415
430
460
2Top Tube (EFF)
572
598
625
652
3Head Tube
95
105
120
130
4Chainstay
440
440
440
440
5BB Drop
65
65
65
65
6BB Height
310
310
310
310
7Wheelbase
1181,8
1210,1
1240,6
1269,9
8Head Angle
64,5
64,5
64,5
64,5
9Seat Angle
77
77
77
77
10Rake
44
44
44
44
11Standover
440
440
440
440
12Reach
427
451
475
500
13Stack
633
642
655,5
664,5
14Fork Length
554
554
554
554
Size
Height
S
150-165
M
160-175
L
170-185
XL
180-198

*Estimated measurements
